Customized Non Asbestos Composite Sheet Cylinder Head Gasket Sheet Manfacturer - Paidu Group

No.049

Mainly composite by beater paper and metal sheet. It is the best material of cylinder head gasket. It is used for machinery of equipment such as automobile engine, motorcycle engine, diesel internal combustion engine etc. This series include: 1) Reinforced Composite gasket Sheet (beater paper+tinplate+beater paper) 2) Reinforced Composite Sheet with Both Size Coating Graphite 3) Exhausted engine gasket sheet (tinplate+beater sheet+tinplate) 4) Reinforced Non-Asbestos Sheet with Both Size Coating silicon (anti stick)


$2.80
  • Non Asbestos Composite Sheet Cylinder Head Gasket Sheet Manfacturer - Paidu Group
  • Non Asbestos Composite Sheet Cylinder Head Gasket Sheet Manfacturer - Paidu Group
  • Non Asbestos Composite Sheet Cylinder Head Gasket Sheet Manfacturer - Paidu Group
  • Non Asbestos Composite Sheet Cylinder Head Gasket Sheet Manfacturer - Paidu Group
  • Non Asbestos Composite Sheet Cylinder Head Gasket Sheet Manfacturer - Paidu Group
  • Non Asbestos Composite Sheet Cylinder Head Gasket Sheet Manfacturer - Paidu Group
Desciption
Product Parameters
Item
Standard data
Density (g/cm³)
1.3~1.5
working temperature (℃)
150~300
Compressibility (%)
10±5
Recovery ≥ %
40
Sealing performance
<0.5cm3/min
Causticity
Cusp no rusty
Tensile strength (MPa ≥)
12.7
Compressive Strength (MPa ≥)
80.0
Carbon content ≥ %
98
Ash content<%
1
